Soundproof Diesel Container Type Generator Genset 800KVA Cummins With Containerized Canopy

Brand Name : SHX

Model Number : SCF800

Certification : ISO9001:2015, CE, TUV, BV

Place of Origin : Foshan, China

MOQ : 1 Set

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 5 Sets per month

Delivery Time : 30 working days

Packaging Details : Standard export packing

Product name : 800VA Soundproof Generator

Color : White

Frequency : 50Hz / 60Hz

Speed : 1500RPM / 1800RPM

Alternator Type : Single Bearing

Control Panel : Smartgen HGM6110N

Contact Now

Soundproof Diesel Generator 800KVA Cummins Genset With Containerized Canopy

Specification of generator set

  1. Prime power: 800KVA / 640KW
  2. Rated voltage: 400V / 230V
  3. Rated frequency: 50Hz
  4. Rated speed: 1500RPM

Benefits

  • Function stability credibility service convenience.
  • Low operating cost results in optional economy.
  • Gets the job done wherever you are.
  • Easy for installation, operation and maintenance.
Genset Specifications:
Genset model SCF800
Genset rated power 800KVA/640KW
Rated voltage 400/230V (adjustable)
Rated current 1152 Amps
Frequency 50 Hz
Power factor 0.8 Lagging
Connecting type 3 phase 4 wire
Cooling system Closed cycle water-cooled with fan, water tank
Overall dimension (L×W×H) mm 6058×2438×2591
Gross weight (kg) 9800
Engine Specifications:
Diesel Engine
Brand CCEC CUMMINS
Model KTA38-G2B
Engine type 12 cylinders in Vee form,4 stroke, direct injection
Aspiration Turbocharged and water-to-air aftercooled
Rotating speed 1500 RPM
Engine cooling system Water-cooled
Speed governing system Electronic speed governor
Starting method By 24V batteries
Engine filter system Dry type air filter ,fuel filter, oil filter, water filter
Displacement(L) 38
Bore×Stroke(mm) 159×159
Compression ratio 15.5: 1
100% Load fuel consumption (g/kw.h) ≤204
Lube capacity(L) 98.6
Alternator Specifications:
Alternator
Brand FARADAY
Model FD6A1-4
Excite type Brushless self-excited AVR regulation
Connecting type 3 phase 4 pole
Steady frequency change 0.50%
No load voltage ≥95%-105%
Steady voltage ≤±1%
Insulation class Class H
Protection grade IP23

Control System

  • Control, monitor and protect the Generator Set
  • High water temperature
  • Low oil pressure
  • Over and under speed
  • Over current
  • Under/Over generator voltage
  • Start and stop failure
  • Low and high battery voltage
  • Charge fail
  • Emergency stop
